Original Multiple Cutting-edge Technology
A Global Initiative
The First Nestle with Fast Auto-charging Commercial Application
Endless Flight and Multi-shows
Automatic charging
High Safety and reliability of 99.999%
Flexible and efficient venue arrangement
Fully Automatic Flight
Endless Flight and Multi-shows
Automatic charging
Outstanding Image Display Capability
More delicate image, leading the new standards in the industry
Millimeter Accuracy
Upgraded Filling Algorithm
Real-time Full Image Restoration
Full Color Strobe Light
Adaptive Strategies for Complex Site Challenges
One-click termination
Upgraded waterproofing, no fear of light rain
Operating Temperature Range: -20℃ to 50℃
Support takeoff from 11 complex sites
Parachute Protection
security assurance
The flight reliability is increased to 99.999%
Triple backup, upgraded safety 5G WiFi, 2.4G Radio, and 900M Radio
Take Your Sky Story From Concept To Reality
Design Software Upgraded
Drama design is compatible with more design software, which significantly reduces the learning cost for operators
Algorithm Upgraded
The time efficiency of generating take-off and landing drama for 10,000 drones has been increased by 10 times, and the efficiency of drama production has been increased by 3 times, which has greatly reduced the workload and time of drama production
V4 Parameter
-
Dimension308mm*308mm*124mm
-
Wheelbase230mm
-
Weight565g
-
Max Wind Resistance Velocity8.0-10.7m/s
-
Suggested Show TimeWithin 15 min
-
Location Solution(GPS+BDS+GLONASS) &RTK upgraded
-
Positioning AccuracyHorizontality ± 8mm, verticality ± 15mm
-
Battery Installation MethodBuilt-in
-
Charging MethodAuto Charged after landing
-
Power-on MethodRemote power-on by batches
-
Capacity of Docking Case30 pcs
-
Maximum Cruising Velocity10m/s
-
Power of Light24W
-
Site Demands1000 drones only takes an area of 250 square meters
-
Communication Distance2km
-
Operating Temperature Range-20℃-50℃ (Below 0°C, preheating is required)
-
Waterproof LevelIP54
-
Security AssuranceAuto Parachute Protection
-
Parachute Opening Altitude30m-60m
-
Shows Capability of a Single-Power Station3 Shows
-
Interval for Re-flight40min-60min (Auto charged, battery replacement-free）
